1g or 2g 7Bolt how can the difference :?

Vr4junkie

Well-known member
Joined
Jun 25, 2011
Messages
596
Location
Some wack town in CA
ok i bought a 7bolt block the guy said it was a 1g 7bolt i think off a 93 well the motor ended up having a spun bearing so i plan on rebuilding this block to stock specs but before i start rebuilding this motor i want to make sure its a 1G 7Bolt or else i wont even bother messing with it guy said it was a 1g but thats what he said about the block being good running condition which i got screwed over /ubbthreads/images/graemlins/banghead.gif
so how can i tell the difference is there like some serial numbers


GSX_TC

Well-known member
Joined
Apr 7, 2011
Messages
3,729
Location
Houston, Texas
1G head
-Bigger intake ports
-12mm head studs (1.25 pitch?)
-Hall or optical effect CAS on intake cam, passenger side
-Slightly more aggressive stock cams

2G head
-Smaller, higher-velocity intake ports
-11mm head bolts (pitch?)
-95-96 CAS is underneath the intake cam gear on, on passenger side on 97+
-Detuned cams

Misc Differences
-Different thermostats
-Some brackets on the 2g absent on the 1g


and here's a link how to tell them apart from the blocks in various ways click


beaner

Well-known member
Joined
Jun 22, 2005
Messages
1,562
Location
b'ham, mi
He's asking about the difference between a 1g 7bolt block and 2g 7bolt block. You're talking about heads and 6bolt oil pans. But your post count did go up a couple ticks.

click


89Mirageman

Well-known member
Joined
Jul 5, 2006
Messages
2,502
Location
Stantonsburg, NC
1g 7 bolt will have the 1g style oil squirters. Also if it came from a mitsu and not a talon or laser it will have a VIN stamped on it. Run the VIN on carfax for the year model.


GSX_TC

Well-known member
Joined
Apr 7, 2011
Messages
3,729
Location
Houston, Texas
Show me the Carfax!




OMFGeofffff

Well-known member
Joined
May 5, 2006
Messages
867
Location
Burnsville, MN
If it's a 2g 7bolt then it won't have holes on the back to bolt a motor mount. 2g's had the front, tranny and rear mounts on the transmission.


donkeylips

Well-known member
Joined
Jun 18, 2009
Messages
552
Location
Rochester, NY
^^^ You can't run a 2g block in a 1g or gvr4 because of this. That's going to be an easy way to tell. Also with the VIN. Not that a 1g 7-bolt can't work well, but I wouldn't bother with one when you can get a 6-bolt so easily.


Vr4junkie

Well-known member
Joined
Jun 25, 2011
Messages
596
Location
Some wack town in CA
thanks for the links really helped out so i guess i have a 1g 7Bolt how reliable are the 1g 7bolts? I plan on rebuilding this block and just get my car up and running something just to mess around on the weekends and Build my 6Bolt up on the side... but i been hearing alot about CrankWalk but i dont know if its as bad as people make it seem to be so is it even worth rebuilding this block i just need something for mean while


beaner

Well-known member
Joined
Jun 22, 2005
Messages
1,562
Location
b'ham, mi
Couple years ago I popped the bottom end of my 6bolt and swapped in a 1g 7bolt shortblock. Figured it wasn't prone to cw and no one wanted to touch it because it was a 7bolt. Win win. After the swap it ran PERFECT and was awesome to drive. About 900 miles into it, the clutch would get a little soft around left turns, idle would bog hard at red lights for no reason. I remember driving in denial for a few hundred miles before accepting that it walked and had to be ripped out. The crank had like 1/4" play side to side. Personally I will never touch a 7 bolt again just because of all the wasted effort and time. I have no hate for 7bolts and if I bought a car that already had one I would leave it be, but for swapping, never again.

As for the swap itself, I'm trying to think of what was different. It was minor stuff. I had to drill out the head for the larger headstuds. My 7bolt was out of a FWD because the front/rear motor mounts were wrong, so that meant I had to modify the starter plate for an AWD flywheel. Had to get 1 flywheel bolt and 7 bolt flywheel obviously. The oil pump and front case is different, the tensioner is different, oil pan is different. I had to cut up my 6 bolt timing belt cover to clear everything. I should have used a 7bolt timing cover to properly set my ignition timing. I'm sure there's other little things I'm forgetting.

If you need any 1g 7bolt accessories let me know. My walked block went to the scrap yard but I kept all the accessories.


89Mirageman

Well-known member
Joined
Jul 5, 2006
Messages
2,502
Location
Stantonsburg, NC
I know when I rebuilt a 1g 7 bolt engine for my last Colt all of the main and rod bearings were different when I ordered them from Mitsubishi. I had to keep up with them when I removed them and each one had #'s stamped on the back. I used those #'s to order new ones. It was a PITA.

You can't just order a set of after market acl's like you can for a 6 bolt.


pauleyman

Well-known member
Joined
Feb 27, 2011
Messages
91
Location
Oklahoma City, OK
I don't know why people bitch about any of the 1g 7 bolts motors. THe problems I see in any of the cars have always boiled down to somebody didn't do something right and/or the clutch was way too heavy. The number one thing I've seen over and over and over again is people not knowing how the clutch hydraulics work and even better those stupid extended clutch rods. They do not work. period. They CAN change the engagement of the clutch. Bonus points for anybody that can tell me why.
